TRUPULSE 360i

$2,995.00 + GST

Out of stock

SKU: 7005855 Categories: , , , ,

The TruPulse 360i fuses a tough, highly accurate, and intuitive next-generation rangefinder design with our patented TruVector 360° Compass Technology, enriching your laser measurements with azimuth data.

Description

i-Series rangefinders are made to measure from the ground up. The TruPulse 360i is capable of 50% higher distance accuracy and 60% higher inclination accuracy than the previous TruPulse 360° model while increasing the overall effective range by 25%. Faster target acquisition speeds and new feedback features boost confidence in each measurement.

Take your measurements up a notch with TruVector 360° Compass Technology. The TruPulse 360i adds azimuth data to your measurements allowing efficient, single-shot positioning of remote features and 3D point-to-point calculations, a major advantage when completing projects that require accurate asset location and facility mapping.

This next-generation laser rangefinder gives you confidence for every measurement with faster target acquisition speeds along with visual feedback for each shot. Use Bluetooth Dual Mode to expand connection capabilities. Challenging targets are no match for the ultra-bright heads-up display with 5 brightness levels to work in any lighting condition. This rugged unit is built to last with a lightweight and strong magnesium chassis and rubber-armored aluminum housing with a 100% waterproof rating.

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc., and any use of such marks by Laser Tech is under license.

Additional information

Brand

TruPulse

Ranging Performance

50cm – 2,500 Meters (20 in – 8,202 ft)

Distance Accuracy

10 cm < 1,000 m (4 in < 3,280 ft), 20 cm > 1,000 m (8 in > 3,280 ft), High-Quality target, Low-Quality target

Azimuth Accuracy

< 1.0° RMS

Distance Precision

0.01 = High-Quality Target, 0.1 = Low-Quality Target

Inclination Accuracy

0.1° @ 0° to +/-30°, 0.2° @ +/-30° to +/-90°

Scope Magnification

Optics: 5X

In-Scope Display Type

5 Brightness levels, Ultra Bright LED HUD

Wireless Communication

Android™, Bluetooth V4.0 Dual Mode: BLE / Classic BT, iOS, Windows®

Environmental Rating

IP67: Waterproof & Dustproof

Battery Type

Two AA

Battery Life

~ 3,600 measurements

Operating Temperature

-20°C to +60°C. (-4°F to 140°F)

Size

Height – 88 mm
Width – 43.4 mm
Length – 118.3 mm

Weight

382.6 g(with batteries)
337.4 g (without batteries)

Eye Safety

CLASS 1 LASER PRODUCT: Product complies with IEC60825-1 Ed. 3:2014-5 and 21CFR1040.10/11 per Notice 50:2007

Videos

Downloads

TruPulse® 360𝗂 BrochureDownload
TruPulse 360i Compass Calibration SheetDownload
TruPulse 360i User ManualDownload
TruPulse 360i Quick Reference Field GuideDownload
Professional Measurement Product SolutionsDownload

Primary Applications

Construction: Crane Positioning

Forestry: Engineering, Surveys, Tree Heights

GIS / GNSS Mapping: LaserGIS mapping laser offset

Utilities (EU): Pole Audit, Vegetation Management

Utilities (Public Works): Water/Gas/pipeline

Telecommunications / Wireless: Small Cell

Mining: Stockpile Volume



Key Features

Measurement

Provides measurement capability with distance, azimuth & inclination values.

Accuracy (Range)

50% Increased range accuracy, can achieve 10cm accuracy when higher accuracy jobs demand nothing less.

Accuracy (Tilt Inclination)

More Precise Tilt Accuracy: 2.5X more precise tilt measurement (0.1° vs. 0.25°)

Accuracy (Compass)

Confidence in repeatable azimuth measurement; less than 1 Degree

TruTargeting

Faster acquisition, greater accuracy, and visual feedback upon target acquisition means confidence, efficiency, and greater safety in the field.

LTI TruVector 360° Compass Technology®

  • Produces accurate and repeatable Azimuth (AZ) results regardless of the tilt or pitch used when aiming the laser
  • Intuitively recognizes conditions that will affect the reliability of the compass accuracy and prompts you to recalibrate
  • Calibration is easily done with a simple field routine that can be completed in less than a minute

Targeting Mode

Advanced Targeting Modes (Closest, Farthest, Continuous and Filter).

Ergonomics

Easy to hold and operate with rubberized grips and tactile button feedback.

Rugged

Withstands harsh conditions with rugged, waterproof, dustproof housing. designed with a strong magnesium chassis and rubber-armored aluminum housing for extra durability. Holds up to everyday uses under any conditions.

On Board Calculations

Auto calculates horizontal distance, vertical distance, height and 3D missing line values; inclination Percent Slope.

Optics/Display

The new Ultra-Bright Display has five brightness settings and works in any lighting condition. Our enhanced optical designs provides 80% light transmission, which simply means you will be able to see with greater clarity and bring smaller hard to see objects into focus.

Communicates with multiple platforms

Bluetooth Dual Mode: BLE and Classic BT options; Android, iOS & Windows Compatible.

User Experience

Intuitive User Interface and workflows with an icon driven display to provide 7 onboard measurement solutions.
